28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor

Name: 28X28X45mm 18 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor
Brand: Casun
Price: 1 USD

Buy cheap 28X28X45mm 1.8 Degree 2 Phase NEMA 11 Stepper Motor With Encoder Close Loop Servo Motor product

Brand Name : Casun

Model Number : 28SHD4414-15BQ

Certification : CE,ROHS,ISO

Place of Origin : CHINA

MOQ : 1PC

Payment Terms : D/A, T/T, L/C, D/P

Supply Ability : 40000+PCS+Month

Delivery Time : 7-15 days

Packaging Details : Carton:38x29x18cm

color : black

Current / phase : 0.95Amp

Holding torque : 98mN.m

Weight : 0.14 kg

Size : NEMA 11

Rated Current : 0.95 A

Customized : The motor can be designed &manufactured with customized request.

Contact Now

Motors with reducers can achieve more complex motion control, such as precise adjustment of speed and position.

Applied to precision positioning, laboratory equipment, medical equipment.

Features:

Bipolar or unipolar versions available
Hybrid stepper construction
Expert in drivetrain solutions
Our engineering team will reach out within 48 hours to deliver the optimal solution
Customizations on request

Dimensions

Motor Specifications

Step Angel	1.8 °
Fram Size	42 mm
Number of Phase	2 Phase
Rated Current	0.95Amp
Holding Torque	98mN.m
Resistance	3.2 hm
Inductance	2.7mH
Rotor Inertia	12g-cm²
Motor weight	0.14 kg
Encoder Pulsh	2500
Connection	Bipolar

Operating Specifications

Motor

Step Angle: 1.8°

Maximum Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Encoder

Voltage: 5 v

Output: A + A - B + B - Z + Z -

Torque Curves

Submodels

Model	Holding Torque	Step Angle	Length	Type of Shaft	Rated Current
42SHD4950	0.13N.m	1.8°	20mm	D Shaft-20mm	1.0A
42SHD4003	0.26N.m	1.8°	34mm	D Shaft-20mm	0.4A
42SHD0261	0.45N.m	1.8°	40mm	D Shaft-20mm	1.68A
42SHD4425	0.59N.m	1.8°	48mm	D Shaft-24mm	2.0A
42SHD4813	0.8N.m	1.8°	60mm	D Shaft-24mm	2.1A

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft
