NEMA 34 Closed Loop Hybrid CNC Stepping Motor 12N.M 150mm Length With Encoder

NEMA 34 Closed Loop Hybrid Motor CNC Stepping Motor 12N.M 150mm Length With Encoder

The feedback signal of the encoder can be used to detect whether the motor has lost step.

By utilizing the feedback information from the encoder, the reverse movement of the motor can be detected.

Features:

• Bipolar or unipolar versions available

• Having operated in China for 12 years, we have served over 800 customers

• Available in single or double shaft versions

• Each model of our stepper motor is suitable for various scenarios

• Our engineers will contact you within 48 hours to offer the best solution

Motor Specifications

Operating Specifications

Step Angle: 1.8°

Maximum  Temperature :80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range (%) :85% or less, non-condensing

Magnet Wire Insulation :Class B 130 deg C

Insulation Resistance :100M Ohm at 500 VDC

Dielectric Strength :500 VDC for 1 min

Encoder

Voltage: 5 v

Output: A + A - B + B - Z + Z -

Torque Curves

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs

Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
            Encoder          |               Brake           |              Gearbox            |           Shaft

Please click the "Get  a quote" button below to tell us your requirements.
